BTC insulated conductor rail 3P,4P,6P

BTC insulated conductor rail 3P,4P,6P

Share on FacebookTweet about this on TwitterShare on LinkedInShare on Google+
INQUIRY

continuous type insulated conductor rail system, CE certificate.

Type Poles Conductor cross section(mm2) Max.current(A)
BTC3-50/10mm2 3 3x10mm2 50A
BTC3-80/16mm2 3 3x16mm2 80A
BTC3-100/20mm2 3 3x20mm2 100A
BTC3-120/25mm2 3 3x25mm2 120A
BTC3-140/35mm2 3 3x35mm2 140A



Type Poles Conductor cross section(mm2) Max.current(A)
BTC4-50/10mm2 4 4x10mm2 50A
BTC4-80/16mm2 4 4x16mm2 /3x16mm2+1x10mm2 80A
BTC4-100/20mm2 4 4x20mm2 /3x20mm2+1x10mm2 100A
BTC4-120/25mm2 4 4x25mm2 /3x25mm2+1x10mm2 120A
BTC4-140/35mm2 4 4x35mm2 /3x35mm2+1x10mm2 140A
