HFP series enclosed type conductor rail system for hoist, crane and many movable power supply system. plastic & aluminum cover.
| Type | Poles | Conductor cross section(mm2) |
Max. current (A) |
Leakage- distance(mm) |
Max. voltage (V) |
Resistance (Ω/km) |
Unit weight (kg/m) |
| HFP56-4-10/50 | 4 | 4×10 | 50 | 35 | 600 | 1.656 | 2.16 |
| HFP56-4-12/65 | 4 | 4×12 | 65 | 35 | 600 | 1.321 | 2.23 |
| HFP56-4-15/80 | 4 | 4×15 | 80 | 35 | 600 | 1.137 | 2.3 |
| HFP56-4-20/100 | 4 | 4×20 | 100 | 33 | 600 | 1.011 | 2.43 |
| HFP56-4-25/120 | 4 | 4×25 | 120 | 33 | 600 | 0.713 | 2.56 |
| HFP56-4-35/140 | 4 | 4×35 | 140 | 33 | 600 | 0.522 | 2.95 |
| HFP56-4-50/170 | 4 | 4×50 | 170 | 33 | 600 | 0.337 | 3.25 |
| HFP56-4-70/210 | 4 | 4×70 | 210 | 33 | 600 | 0.265 | 3.85 |
| HFP56-4-80/240 | 4 | 4×80 | 240 | 30 | 600 | 0.223 | 4.16 |
